Miniature DC Motor Driver Breakout Board - am-3648 - migrated

Miniature DC Motor Driver Breakout Board

by AndyMark
$8.90 USD - $8.90 USD
$8.90 USD
$8.90 USD
$8.90 USD - $8.90 USD
$8.90 USD
This motor breakout board is handy for use with DC motors and is simple to install.
SKU am-3648
  • Description
  • Specifications

  • Connect your motor to the OUT terminal block. Power the board with 6.5-45VDC power on VMotor and provide the H-bridge input control on IN1 and IN2. You can even PWM the inputs and the driver chip will do the right thing. The 30K resistor (~2A current limit) can be removed and replaced with a resistor of your choice of resistance and limit.

    You can find a detailed tutorial here, and an assembly guide here.

    This motor driver is NOT legal for use in any FIRST programs.

    • Dimensions: 1 in. x 0.8 in. x 0.4 in.
    • Manufacturer: Adafruit Industries
    • Manufacturer Part #: 3190
    • Motor Power Voltage: 6.5 V - 45 V
    • Peak Current: 3.6 A
    • Weight: 0.1 oz.

Not Returnable

This product is not eligible for returns. All sales are final.
